ANSI B16.5, ASA B16.5, 150LBS, 300LBS, SLIP ON FLANGE, FF, RF

Views: Post Date: 1/16/2013 6:29:32 AM

Flange ID: Pro-20130116-000289
Standard: ANSI B16.5, ASA B16.5
Type: SLIP ON FLANGE, FF, RF	Material: A105
Size: 1/2” - 48”	Process: Forging, Forged
Supply Ability: 2500TON/MONTH	Min. Order: 50Pcs
Supplier: Jinan Hyupshin Flanges Co., Ltd Origin: Shandong, China Certificate: ISO9001:2008, KS, PED, AD2000 Packing: PLYWOOD PALLET Payment Terms: T/T, L/C

JINAN HYUPSHIN FLANGES CO., LTD supply ANSI B16.5, ASA B16.5, CLASS 150, CLASS 300, CLASS 600, SLIP ON FLANGE, FF, RF, BLACK PAINT COATING, monthly output 2500Ton..

Standards & Types:

1) ANSI B16.5, CLASS 150, 150LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

2) ANSI B16.5, CLASS 300, 300LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

3) ANSI B16.5, CLASS 600, 600LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

4) ANSI B16.5, CLASS 900, 900LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

5) ANSI B16.5, CLASS 1500, 1500LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

6) ANSI B16.5, CLASS 2500, 2500LBS, SLIP ON FLANGE, FF RF, SO HUB FLANGE, 1/2"-40", A105.

Material:

CARBON STEEL: P245GH, P250GH, S235JR, RST37.2, C22.8, A105.

STAINLESS STEEL: 304, 304L, 316, 316L, 1.4404, 1.4306, 1.4307.

Surface Antirust:

Surface antirust 1: Antirust light oil

Surface antirust 2: Black paint coating

Surface antirust 3: Yellow paint coating or Red paint coating

Surface antirust 4: Galnavized (Hot galvanized or Cold galvanized or Electro Galvanized)

Surface Finish:

Surface finish 1: Stock finish

Surface finish 2: Sprial serrated

Surface finish 3: Two or three grooves (Water Lines)

Surface finish 4: Smooth finish

Keywords: ANSI B16.5 WELDING NECK FLANGE CLASS 150, ANSI B16.5 WELDING NECK FLANGE CLASS 300, ANSI B16.5 WELDING NECK FLANGE CLASS 600, ASA B16.5 FLANGE, JINAN HYUPSHIN FLANGES CO., LTD
