HIGH QUALITY LOOSE FLANGES, EN1092-1 TYPE02 FORGING FLANGES, PN6 PN16 PIPE FLANGES

Views: Post Date: 10/15/2015

Exporting	HIGH QUALITY LOOSE FLANGES, EN1092-1 TYPE02 FORGING FLANGES, PN6 PN16 PIPE FLANGES	Quantity	5000Pcs
Standard	EN1092-1	Size	1/2INCH, 24INCH
Material	ASTM A105N	Price	Inquire
Post Date	10/15/2015 7:56:25 PM	Validity Date	1/13/2016

JINAN HYUPSHIN FLANGES CO., LTD is specialized in producing and exporting carbon steel flanges, the annual output is 3000 tons of flanges per month.

The steel flanges of EN1092-1, EN1092.1 standards include:

(1) EN1092-1 Type 01B, Plate Flange, Flat Flange, Plain Flange, PN6, PN10, PN16, PN25, PN40, PN63, PN100, C22.8, RST37.2, S235JR, P245GH, P250GH, P265GH Carbon Steel, DN15-DN2000.

(2) EN1092-1 Type 02, Loose Flange, Lapped Flange, PN6, PN10, PN16, C22.8, RST37.2, S235JR, P245GH, P250GH, P265GH Carbon Steel, DN15-DN1000.

(3) EN1092-1 Type 05, Blind Flange, Blank Flange, PN6, PN10, PN16, PN25, PN40, PN63, PN100, C22.8, RST37.2, S235JR, P245GH, P250GH, P265GH Carbon Steel, DN15-DN2000.

(4) EN1092-1 Type 11, Weld Neck Flange, WNRF Flange, PN6, PN10, PN16, PN25, PN40, PN63, PN100, C22.8, RST37.2, S235JR, P245GH, P250GH, P265GH Carbon Steel, DN15-DN1500

(5) EN1092-1 Type 13, Threaded Flange, Screwed Flange, PN6, PN16, C22.8, RST37.2, S235JR, P245GH, P250GH, P265GH Carbon Steel, DN15-DN150.

Material

1) Carbon Steel A105 & Stainless Steel SS304, SS316, SS316L

Surface Antirust:

Surface antirust 1: Antirust light oil

Surface antirust 2: Black paint coating

Surface antirust 3: Yellow paint coating

Surface antirust 4: Galnavized (Hot Dipped Galvanized or Cold Galvanized or Electro Galvanized)

Surface Finish:

Surface finish 1: Stock finish

Surface finish 2: Sprial serrated

Surface finish 3: Two or three grooves (Water Lines)

Surface finish 4: Smooth finish

Terms

1) Payment: Irrevocable L/C at sight or T/T, D/P

2) Delivery term FOB China Port or CIF Buyer's Port

3) Packing: Plywood Pallet

4) Minimum Order Quantity: 100Pcs.

HIGH QUALITY LOOSE FLANGES, EN1092-1 TYPE02 FORGING FLANGES, PN6 PN16 PIPE FLANGES


Keywords:	Inquire

Supplier: Null           Contact: Null (Null)
Enquiry & Purchasing: Null         Whatsapp: Null
Tel: Null   Fax: Null        Website: www.hsflange.com | www.hsflanges.com

Prev: BLIND FLANGES EN1092-1/05, HIGH QUALITY BLRF BLFF FLANGES, PN10 PN25 CARBON STEEL FLANGES

Next: EN1092-1 TYPE02 LOOSE PIPE FLANGES, PN10 PN16 FORGING LOOSE FLANGES, HIGH QUALITY LOOSE FLANGES
